Understanding the Threat and UK Standards

When considering security in glazing, it's crucial to understand how intruders typically attempt to gain access. Statistics show that most break-ins occur through forced entry via ground-floor windows or doors. Modern security features are designed specifically to counter these common methods: 'smash and grab' (breaking the glass) and 'jemmying' (forcing the frame or hardware).

UK Building Regulations and Security

In the UK, specific standards govern the security performance of windows and doors, particularly those installed in new builds or major renovations. The primary standard referenced is Approved Document Q (Security – Dwellings) of the Building Regulations. Although Document Q is mandatory for new dwellings, it serves as an excellent benchmark for all homeowners seeking high security.

• PAS 24:2016: This Publicly Available Specification is the primary test standard referenced by Document Q. It assesses the security performance of doors and windows against common methods of forced entry, including manual attack tests (using tools like chisels and crowbars) and mechanical load tests.
• Secured by Design (SBD): While not a regulation, SBD is a police-preferred specification scheme. Products carrying the SBD logo have been tested to meet stringent security requirements, usually exceeding the minimum requirements of PAS 24.

Glass Specification for Impact Resistance

The glass itself is often the first point of attack. Moving beyond standard annealed glass is essential for achieving true security. Modern glazing systems utilise toughened and, more importantly, laminated glass to resist impact and prevent easy access.

Laminated Security Glass

Laminated glass is the gold standard for security glazing. It consists of two or more panes of glass bonded together by one or more layers of Polyvinyl Butyral (PVB) interlayer. If the glass is struck and shatters, the fragments adhere to the PVB layer, maintaining the integrity of the pane and preventing a hole from being created.

• P-Ratings (EN 356): Security glass is rated using the European standard EN 356, which classifies resistance to manual attack. P1A to P5A ratings are based on resistance to a steel ball drop test, while P6B to P8B ratings relate to resistance against repeated axe attacks.
• P1A/P2A: Suitable for general domestic applications, offering good resistance against casual vandalism.
• P5A: Often the minimum recommended standard for high-security domestic glazing, offering significant delay against forced entry.

Toughened (Tempered) Glass

While toughened glass is four to five times stronger than standard glass and shatters into small, relatively harmless pieces, it is generally less secure than laminated glass for forced entry prevention. Once broken, it creates a large, immediate hole, allowing access. Therefore, security glazing often combines an outer pane of toughened glass with an inner pane of laminated glass for maximum protection and safety.

Hardware and Locking Mechanisms

Even the strongest glass is useless if the frame can be easily prised open or the locks compromised. Modern glazing relies on sophisticated, multi-point locking systems and robust hardware components.

Multi-Point Locking Systems

Modern doors and windows typically feature multi-point locking systems that engage at several points along the frame when locked, rather than just a single central latch. These systems often include:

• Hook Locks: These hooks penetrate deep into the frame keeps, making it extremely difficult to pull the sash away from the frame.
• Deadbolts/Shoot Bolts: These bolts extend vertically (top and bottom) and horizontally (sides) into the frame, securing the corners.
• Compression Rollers (Mushrooms): These pull the sash tightly against the frame, enhancing weather sealing and preventing the insertion of tools to jemmy the frame.

Cylinder Security and Anti-Snap Technology

For doors, the lock cylinder is a common weak point. Intruders often use techniques like snapping, bumping, or drilling to defeat standard cylinders. High-security cylinders certified to TS007 3-star rating or the Sold Secure Diamond Standard (SS312) are essential. These cylinders incorporate:

• Anti-Snap Features: Designed to break at a sacrificial point, leaving the locking mechanism intact and preventing access.
• Anti-Drill Pins: Hardened steel pins prevent the drill bit from penetrating the cylinder mechanism.
• Anti-Pick Tumblers: Internal mechanisms designed to resist lock-picking techniques.

Hinge Security

Outward-opening windows and doors are vulnerable if the hinges are exposed externally. Modern security glazing addresses this with:

• Dog Bolts/Hinge Protectors: These pins engage into the frame when the door or window is closed. Even if the hinges are removed or cut, the dog bolts keep the sash securely fixed to the frame, preventing it from being lifted out.
• Internal Hinges: Used frequently in high-end aluminium systems, these conceal the hinge mechanism entirely within the frame profile.

Frame Materials and Design

The frame material and its structural integrity play a significant role in overall security performance. Different materials offer varying levels of inherent strength and require specific reinforcement.

Beading and Glazing Security

The method used to hold the glass unit within the frame is critical. Historically, external beading (where the glass retention strips are on the outside) was a major security risk, allowing intruders to simply remove the strips and lift the glass out. Modern security glazing uses internal beading, meaning the glass unit can only be removed from inside the property, rendering this method of attack ineffective.

The Comprehensive Benefits of High-Security Glazing

Investing in glazing that meets or exceeds standards like PAS 24 offers benefits far beyond simple break-in prevention. It contributes significantly to the overall resilience and value of your home.

Maintenance and Long-Term Considerations

Even the best security features require proper installation and ongoing maintenance to remain effective. A poorly installed PAS 24 window will quickly lose its security rating.

• Installation Integrity: Ensure the frame is fixed securely to the structure using appropriate fixings (e.g., frame anchors) and that the installation adheres to the manufacturer's security specifications.
• Hardware Maintenance: Regularly lubricate all moving parts of the multi-point locking system (hooks, rollers, bolts) to ensure smooth operation. Sticking locks can lead to homeowners failing to fully engage all locking points.
• Gasket Condition: Check that the rubber gaskets and seals remain intact. These are crucial for maintaining the compression required for the anti-jemmy features to function correctly.

In summary, modern glazing security is a holistic system. It relies on the synergy between robust, internally beaded frames (aluminium or reinforced uPVC), high-performance laminated glass (P5A minimum), and certified multi-point locking hardware (PAS 24 and TS007 3-star). By understanding these components, UK homeowners can significantly upgrade their property's defence against forced entry.
